Training and Validation

Dataset: The Foundation of MLPs¶

A good machine learning potential (MLP) starts with a high-quality dataset. This dataset is typically generated using density functional theory (DFT) calculations and should include:

• Energies: The total energy of atomic configurations.

• Forces: The forces acting on each atom in the system.

• (Optional) Virials: Stress tensors, which are particularly useful for systems under pressure or strain.

What Makes a Dataset Good?¶

• Diversity: The dataset should cover a wide range of atomic configurations, including different geometries, volumes, and chemical compositions.

• Accuracy: The data must be reliable and free from errors. Poor-quality data can lead to poor model performance.

• Coverage: Ensure the dataset represents the conditions the MLP will encounter, such as varying temperatures, pressures, and chemical environments.

Training: How MLPs Learn¶

Training an MLP involves teaching it to predict energies, forces, and stresses from atomic configurations. This process can be broken down into three main steps:

1. Loss Function: The loss function measures how far the MLP’s predictions are from the actual values. A common choice is a weighted combination of mean squared error (MSE) terms for energies, forces, and stresses:

   $$L = w_E \frac{1}{N_{\mathrm{cfg}}} \sum_{i=1}^{N_{\mathrm{cfg}}} \left( E_i - \hat{E}_i \right)^2 + w_F \frac{1}{N_{\mathrm{atoms}}} \sum_{i=1}^{N_{\mathrm{cfg}}} \sum_{a=1}^{n_i} \left\| \mathbf{F}_{ia} - \hat{\mathbf{F}}_{ia} \right\|^2 + w_S \frac{1}{N_{\mathrm{cfg}}} \sum_{i=1}^{N_{\mathrm{cfg}}} \left\| \mathbf{S}_i - \hat{\mathbf{S}}_i \right\|^2$$

   (1)

   • $N_{\mathrm{cfg}}$: Number of configurations.

   • $n_i$: Number of atoms in configuration $i$.

   • $N_{\mathrm{atoms}} = \sum_i n_i$: Total number of atoms in the dataset.

   • $E_i$, $\hat{E}_i$: True and predicted energies.

   • $\mathbf{F}_{ia}$, $\hat{\mathbf{F}}_{ia}$: True and predicted forces on atom $a$ in configuration $i$.

   • $\mathbf{S}_i$, $\hat{\mathbf{S}}_i$: True and predicted stress or virial quantities.

   • $w_E$, $w_F$, $w_S$: Weights used to balance the different error terms.

   In practice, these weights are important because energies, forces, and stresses have different units, magnitudes, and numbers of targets.

2. Optimization: Algorithms like gradient descent are used to minimize the loss function, improving the model’s predictions over time.

3. Hyperparameters: These are settings that control the training process, such as learning rate, batch size, and number of epochs. Tuning these hyperparameters is crucial for achieving optimal performance.

4. Validation: To ensure the MLP generalizes well, test it on a separate validation dataset. This helps detect overfitting and ensures the model performs well on unseen data.

Evaluation: Measuring MLP Performance¶

Once the MLP is trained, it’s important to evaluate its performance. Here are some key aspects to consider:

1. Accuracy:

   • Use metrics like Mean Absolute Error (MAE) and Root Mean Squared Error (RMSE) to assess:

     • Energy predictions (e.g., in meV/atom).

     • Force predictions (e.g., in eV/Å).

   • You also need to check the accuracy of the properties that you are interested in, such as ionic conductivity, etc.

2. Stability in Molecular Dynamics (MD):

   • Test the MLP in MD simulations to check if it maintains stable temperature and conserves energy.

3. Transferability:

   • Evaluate the MLP on new structures or chemistries not included in the training dataset. This ensures the model can handle scenarios it hasn’t seen before.
